Looking for a fast and easy way to install your marine windshield washer nozzle? Here’s a step-by-step installation guide for the DE Marine DEC2758 Windshield Washer Nozzle, a durable, high-flow spray nozzle designed to keep your boat windshield clear in all conditions.
Tools & Materials Needed
- 7/8″ drill bit or hole saw
- Electric drill
- Wrench or socket
- Flathead screwdriver
- Thread sealant or Teflon tape.
- DE Marine DEC2758 nozzle & NPT hose Fitting
-
(Optional) Marine-grade silicone sealant
Step-by-Step Guide: Install DE Marine DEC2758 Boat Windshield Nozzle
1. Choose the Best Mounting Location
Pick a flat area near your windshield wiper path for maximum spray coverage. Make sure there’s space behind the panel to connect the washer hose and fitting.
FAQ: Where should I mount a windshield washer nozzle on a boat?
As close to the center of the wiper sweep area as possible, on a flat surface with rear access.
2. Drill the Mounting Hole
- Use a 7/8″ hole saw or drill bit.
- Drill slowly to avoid gelcoat damage.
- Use painter’s tape on the surface to reduce chipping.
3. Install the Nozzle Body
- Insert the DEC2758 nozzle through the drilled hole.
- Secure it with the provided mounting nut from underneath.
- Tighten with a wrench, snug, not overtightened.
Optional: Apply marine-grade silicone sealant around the flange for extra waterproofing.
4. Attach the Washer Fluid Hose
- The DEC2758 has a 1/8″–27 NPT port.
- Use a compatible NPT-to-hose fitting (sold separately).
- Wrap threads with Teflon tape or sealant.
- Hand-tighten, then snug with a wrench.
Pro Tip: Use DEC Marine’s recommended fittings for best results.
5. Adjust the Spray Angle
- Rotate the nozzle head for left-right (port/starboard) adjustment.
- Use a screwdriver in the slot on top for up-down (vertical) control.
FAQ: How do I aim a boat windshield washer nozzle?
Rotate the nozzle head and fine-tune with a flathead screwdriver until the spray hits the center of your windshield.
6. Test the System
- Activate the washer system.
- Check for leaks at the base and fitting.
- Adjust spray coverage as needed.
Checklist Before You Finish:
- Nozzle firmly mounted
- Hose securely connected
- No leaks
- Spray covers the wiper path
Why Install the DE Marine DEC2758 Windshield Nozzle?
- High flow rate: 3 qt/min @ 30 psi
- Compact & corrosion-resistant: Fits tight spaces, made with nickel-plated metal and anodized aluminum
- Easy to install: Standard marine threads and flange design
- Fully adjustable spray: Dial in precise aim for maximum visibility
Frequently Asked Questions
Q: What size hole do I drill for the DE Marine DEC2758 nozzle?
A: Drill a 7/8-inch hole.
Q: What kind of fitting connects to the nozzle?
A: A 1/8″–27 NPT fitting. Teflon tape or sealant is recommended.
Q: Can I install it myself without a pro?
A: Yes, installation is DIY-friendly and takes about 15–30 minutes.
